Product Description
*** RESERVED FOR CHARLES H ***
Complete rebuilt Chrysler 2.2 turbocharged engine for mild street performance. Forged pistons, full floating HD rods, rebuilt Garrett T1 turbo charger with complete EGR system, Stage 2 calibration for 14 psi boost, T2/T3 clutch assembly, upgraded cylinder head with positive valve stem seals and back cut valves for additional flow. T2/T3 clutch combo package with HD throw out bearing. Picked up and delivered door to door.
Detailed Description
| QTY | ITEM # | DESCRIPTION | UNIT PRICE | LINE TOTAL | ||
| 2.2 Mild Performance Street Build | ||||||
| Application: 1986 Chrysler Laser XT Long Block w/T1 Garrett Turbo, Non-Intercooled, Street, 7-14psi. No nitrous oxide or meth injection, 5 speed A525 transmission. | ||||||
| 1.00 | ENGINE | Complete performance rebuild service customer core provided genuine Chrysler turbocharged 2.2 engine long block, 79,000 original miles. Opened, not running. 8 bolt cast crankshaft | $2,750.00 | |||
| - Tri-metal turbo rod bearings | ||||||
| - Tri-metal turbo main bearings | ||||||
| - Machined crankshaft | ||||||
| - Front crankshaft seal | ||||||
| - Rear main seal | ||||||
| - Intermediate shaft seal | ||||||
| - All gaskets as required (manifold, pan, Valve Cover,WP,etc.) |
||||||
| - Intermediate shaft bearings | ||||||
| - Board and honed for Forged (Wiseco) pistons +20 | ||||||
| - Complete gasket set | ||||||
| - Mobil1 oil filter | ||||||
| 1.00 | Timing belt | |||||
| 1.00 | Stock timing belt tensioner (OEM style/metal not plastic) | |||||
| 1.00 | Wiseco +20 Forged pistons with custom moly rings, performance gaped within .0005”, .0045 cylinder to wall clearance | |||||
| 1.00 | CYLINDER HEAD | Professionally rebuilt genuine Chrysler 782 cylinder head, fast burn. 1 year warranty against cracking. All new valve train hardware: cam, intake & exhaust valves, lifters, roller rocker arms, valve stem seals, cam seals, 3 angle performance valve job. | $649.00 | |||
| · Professional machine shop rebuilt cylinder head · 3 angle valve job · Stock Size Intake & Exhaust Valves · Stock Turbo Valve Springs · Stock Intake/Exhaust Valve Locks/Keepers · OEM Valve Spring Retainers · OEM Roller Cam Followers · New valve guides w/locks as needed · OEM turbo slider Camshaft · Front and Rear Cam Seals · PT Lifters With Shims · Turbo Dodge Parts Positive Valve Stem Seals · Turbo Dodge Parts Ultimate intake studs and copper clad flange nuts · Turbo Dodge Parts Ultimate exhaust studs with copper clad flange nuts · FelPro 11mm head bolts · FelPro Valve Cover Gasket (1 piece or multi-piece design) · FelPro PermaTorqe head gasket - 195* thermostat with housing · Cylinder head core required · Full 1 Year Unlimited Mileage Warranty |
||||||
| T2 style HD connecting rods, machined to Chevy pin | ||||||
| TURBO CHARGER | Garrett TO3/TO4 Rebuild Service | |||||
| - includes complete Chrysler unique EGR system, pipe & valve | ||||||
| - New brass journal bearings (2) | ||||||
| - New 4 piece carbon seal | ||||||
| - New turbine piston seal | ||||||
| - CHRA balancing | ||||||
| Turbo oil and coolant lines | $225.00 | |||||
| - Turbo oil supply line | ||||||
| - Turbo Coolant supply line | ||||||
| - Turbo Coolant return line | ||||||
| - Turbo oil return hose | ||||||
| ENGINE MGMT | Stage 2 Turbo Z Logic Module 12psi boost | |||||
| - Original core required | ||||||
| - Plug-N-Play | ||||||
| - 14 pounds boost, revised spark and fuel curves, modified waste gate tables for faster spool up. O2 feedback, active knock retard, increased rev limiter and over boost protection provided. Revised fan schedules for better cooling. Great for stock or slightly modified turbo 1 cars with stock or 803 injectors, stock map sensor, and stock or larger exhaust. | ||||||
| CLUTCH | Stage 2 Performance clutch (for 225HP or less) | |||||
| - Factory spec T2/T3 combo clutch | ||||||
| - T3 turbo pressure plate | ||||||
| - T2 clutch disk | ||||||
| - Sprung disk center section (anti chatter) | ||||||
| - TIII Pressure plate with the durability of a TII disk to bring you a very affordable combination. This clutch is recommended for both stock and mildly modified applications. Up to 225wheel HP. The kit includes a heavy-duty throw out bearing and clutch alignment tool. | ||||||
| - Fresh genuine Chrysler 8 bolt machined flywheel | ||||||
| SHIFTER | JRS 5 Speed Short Throw Shifter 87-89 style w/o core | |||||
|
CABLES |
87-89 style shifter cables (good used only) | |||||
|
BRAKES |
Solid Rear disk Set, Complete w/hubs, spindles, calipers, backing plates, rubber hose, parking brake accessories and shoes, proportioning valve. |
|
||||
| BODY | T-Top Laser Window Sweeps 1986 | |||||
| Sales tax parts |
|
|
| Sublet Machine | (Included) | |
| Assembly & refinish | ||
| Pickup core and delivery assembled long block: Fayetteville NC |
 |
 |
 |
